Page #370 background imageLoading...
Page #370 background image
エラー
!
スタイルが定義されていません。
エラー
!
スタイルが定義されていません。
エラー
!
スタイルが定義されていません。
Replacement Procedures
エラー
!
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-69
Installing the System board/RJ45 harness/DC-IN harness/USB harness/
Speaker
To install the system board/RJ45 harness/DC-IN harness/USB harness/speaker, follow the
steps below and refer to Figure 4-36 to 4-41.
1. Connect the USB harness and DC-IN harness to the connector CN4613 and
CN8800 on the system board.
2. Arrange the speaker harness and secure it with the acetate tape and insulators.
3. Set the system board to the base assembly.
4. Arrange the speaker harness to the guides and stick the insulators (SQUARE
INSULATOR) in place.
5. Connect the RJ45 harness to the connector CN4050 on the system board.
6. Set the USB harness into the slot and arrange it into the guide.
7. Set the F jack into the slot and secure it with the following screw.
M2.04B BIND screw 1
8. Set the DC-IN harness and RJ45 harness into the slots and arrange them into the
guides.
9. Set the harness holder while engaging the latches.
