Toshiba Qosmio F60 Series Maintenance Manual

エラー ! スタイルが定義されていません。 エラー ! スタイルが定義されていません。
エラー ! スタイルが定義されていません。 Replacement Procedures エラー !
ス
4.29 Heat sink/SPURS heat sink/CPU
Removing the Heat sink/SPURS heat sink/CPU
To remove the heat sink/SPURS heat sink/CPU, follow the steps below and refer to Figure 4-
45 to 4-48.
1. Disconnect the fan harness from the connector CN8771 on the system board.
2. Remove the following screws and heat sink.
 M2.04B BIND screw 4
M2.0x4B BIND
M2.0x4B BIND
Fan harness
CN8771
Heat sink
DUCT insulator
Figure 4-45 Removing the heat sink (1) (internal VGA model)
QOSMIO F60 Maintenance Manual (960-796) [CONFIDENTIAL] 4-75

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
