Replacement Procedures
エラー
!
4. When silicon grease is already applied to the CPU, wipe them off with a cloth in
advance. Apply new grease (Shin-Etsu Chemical Co. X-23-7921-5) on the CPU
using a special syringe as shown in the following figure.
Figure 4-50 Applying new grease
5. If there is already cool sheet on the VGA (external GVA model) or SPURS (SPURS
model), peel off them. Stick new cool sheets on the heat sink or SPURS heat sink in
place.
NOTE: Do not reuse the cool sheet. Be sure to use a new cool sheet.
4-80 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
