Replacement Procedures
エラー
!
4-82 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
(External VGA model)
7. Set the heat sink and it with the following screws.
M2.04B BIND screw 4
M2.03C BIND screw 4
(SPURS model)
8. Set the SPURS heat sink and secure it with the following screws.
M2.03C BIND screw 3
9. Set the heat sink and secure it with the following screws.
M2.04B BIND screw 4
NOTE: When securing the heat sink and SPURS heat sink, be sure to secure the screws
in the order of the number marked on the heat sink and SPURS heat sink.
10. Connect the fan harness to the connector CN8771 on the system board.
To Next Page
