Replacement Procedures
エラー
!
スタイルが定義されて
7. Remove the following screws and brake hinges (left and right) from the LCD unit.
M2.03C S-THIN HEAD screw 8
M2.0x3C
S-THIN HEAD
M2.0x3C S-THIN HEAD
Brake hinge L
Brake hinge R
LCD unit
Figure 4-54 Removing the brake hinge (left and right)
4-86 [CONFIDENTIAL] QOSMIO F60 Maintenance Manual (960-796)
