Toshiba Qosmio F60 Series Maintenance Manual

Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL] Qosmio F60 Series Maintenance Manual (960-796)
Table B-2 System board (FHNSY*) connectors and ICs (back)
Number Name
CN1400 Memory A connector
CN1410 Memory B connector
CN1950 SATA ODD interface connector
CN1930 eSATA/USB interface connector
CN2610 PCI-E Mini(TV) CARD interface connector
CN4612 USB interface connector
CN4613 USB interface connector
CN6150 Speaker interface connector
CN8771 FAN interface connector
IS2100 MEDIA BRIDGE I/F connector
CN5350 HDMI interface connector
CN8800 DC-IN interface connector
CN8810 Battery connector
IS1050 CPU
IC1600 Ibex Peak-M (chip set)
IC500 GPU (10GC only)

Toshiba Qosmio F60 Series Specifications

General

Operating System	Windows 7 Home Premium
Storage	500GB HDD
Webcam	Integrated Webcam
Audio	Harman/Kardon stereo speakers
Connectivity	Wi-Fi 802.11n, Bluetooth
Ports	HDMI, VGA, eSATA, Ethernet
Battery	6-cell Lithium-ion battery
Processor	Intel Core i3 / i5 / i7 (depending on the specific model)
