Troubleshooting Procedures
Qosmio F60 Series Maintenance Manual (960-796) [CONFIDENTIAL] 2-19
1R5-PGV/1R05-P1 output
Error code Meaning
A0h 1R5-PGV/1R05-P1 voltage is over 1.80V.
A1h 1R5-PGV/1R05-P1 voltage is under 0.89V when the computer is powered on.
A2h 1R5-PGV/1R05-P1voltage is under 0.89V when the computer is booting up.
PTV output
Error code Meaning
B0h PTV voltage is over 1.32V.
B1h PTV voltage is under 0.85V when the computer is powered on.
B2h PTV voltage is under 0.85V when the computer is booting up.
PGV/IGD-PGV output
Error code Meaning
C0h PGV/IGD-PGV voltage is over 1.80V.
C1h PGV/IGD-PGV voltage is under 0V when the computer is powered on.
C2h PGV/IGD-PGV voltage is under 0V when the computer is booting up.
SPURS-PPV output
Error code Meaning
D0h SPURS-PPV voltage is over 1.2V.
D1h SPURS-PPV voltage is under 0V when the computer is powered on.
D2h SPURS-PPVvoltage is under 0.85V when the computer is booting up.
1R5-PGV/1R05-P1V output
Error code Meaning
E0h 1R5-PGV/1R05-P1V voltage is over 1.80V.
E1h 1R5-PGV/1R05-P1V voltage is under 0.89V when the computer is powered on.
E2h 1R5-PGV/1R05-P1V voltage is under 0.89V when the computer is booting up.
