1. System Configuration
9
z
Up/down direction is indicated
z
Object vulnerable
to impact
z
Center of gravity is indicated.
z
No wetting
z
Lifting position is indicated
Figure 1.4 Example of Handling Marks
6)
When the equipment as packed is stored, it should be stored in a room with less humidity and
the following storing conditions should be satisfied.
Table 1.3 Storing Conditions
Item Condition
Temperature
-20 to 75
°
C
Humidity 10-90% RH
(No dewing condensation)
z
Unpacking Work
The unpacking work should be done near the installation place with sufficient space and height,
taking care not to damage the equipment.
To remove the nails, use the nail puller and be careful not to give impact.
The checking with the packing list should be done for each package.
To Next Page
