2. Wiring of PCS-DS51
60
Isolation of wiring
Place the serial bus cable more than 2 meters away from power supply lines or devices that
generate electromagnetic fields. When the distance of more than 2 meters is difficult to obtain,
check the actual voltage and current of the inductor and refer to Table 2.7.
The inductor should be less than 440V-100A.
Table 2.7 Recommended Minimum Distance of Separation
Inductor Minimum distance between parallel lines
Current/Voltage 100A Up to 100A or less 50A or less 10A or less
440V Up to 2000mm 2000mm 2000mm 2000mm
440V or less 2000mm 600mm 600mm 600mm
220V or less 2000mm 600mm 600mm 500mm
110V or less 2000mm 600mm 500mm 300mm
60V or less 2000mm 500mm 300mm 150mm
Considering the noise immunity, use a metal cable duct with lid or steel protection duct. Table
2.8 lists the recommended minimum distances of separation for the signal line and power supply
line in case of the parallel wiring.
Table 2.8 Recommended Minimum Distance of Separation (Metal Duct with Lid and
Metal Duct Work)
Parallel Distance
Power in cable
10m or less 25m or less 100m or less
125V or less 10A or less 10 or more 10 or more 50 or more
250V or less 50A or less 10 or more 50 or more 150 or more
400V or less 100A or less 50 or more 100 or more 200 or more
500V or less 200A or less 100 or more 200 or more 250 or more
Power exceeding above 500 or more
(Unit mm)
(Note)
“
Microcomputer Applied Measuring Instrument Installation
Environment Guideline
”
