4RUNNER_U

23

CTHPIAS029

B

∗: If equipped

Vehicles with third row seats

Storage compartment

∗

P. 458

Power outlets

P. 436

Power outlets∗

P. 439

Cargo net hooks

Grocery bag hooks

P. 457

P. 459

Cargo hooks

Cargo net hooks

P. 456

P. 457
