542

4-3. Do-it-yourself maintenance

4RUNNER_U

Replacing light bulbs

n Headlight

Turn the bulb base counterclock-

wise.

High beam (inside)

Low beam (outside)

n Rear bulb locations

CTH43AS102

License plate lights

Rear turn signal

light

Back-up light

Stop/tail and rear

side marker light

CTH43AS126

STEP

1
