3-6. Using the storage features

3

Interior features

4RUNNER_U

n Adjusting the size of the cup holders

Front seats (standard type transmission)

Front seats (multi-mode type transmission)

Rear seats (without third row seats)

Remove the adapter.

CTH36AS039

Remove the adapter.

CTH36AS010

Remove the adapter.

CTH36AS031

Cup holders
