4RUNNER_U

8

Front turn signal lights and daytime

running lights

P. 179, 198

Pictorial index

Exterior

Headlights (low beam)

P. 198

Hood

P. 494

Windshield wipers

P. 205

Moon roof∗

P. 98

Outside rear view mirrors

P. 89

Parking lights and front side

marker lights

P. 198

Fog lights∗

P. 204

Headlights (high beam)

P. 198
