4RUNNER_U

9

Tires

l Rotation

l Replacement

l Inflation pressure

l Information

P. 514

P. 578

P. 621

P. 626

Rear window defogger

P. 310

Rear window wiper

P. 207

Side doors

P. 51

Rear turn signal lights

P. 179

License plate lights

P. 198

Back door

P. 56

∗: If equipped

Stop/tail and rear side

marker lights

P. 198

Fuel filler door

P. 102
