1-3. Adjustable components (seats, mirrors, steering wheel)

4RUNNER_U

Vehicles with third row seats

n Second row seats

Seat position adjustment

lever

Seatback angle adjustment

lever

n Third row seats

The third row seats do not have a seat adjustment function.

CTH13AS053
