556

5-1. Essential information

4RUNNER_U

Vehicles with a front spoiler only:

Before using the front emer-

gency towing eyelet(s), remove

the cover(s).

Removing the clips

Installing the clips

Towing with a sling-type truck

Do not tow with a sling-type truck

to prevent body damage.

CTH51AS007

CTH51AS008
