5

When trouble arises

579

5-2. Steps to take in an emergency

4RUNNER_U

Taking out the jack and tool bag

Remove the cover.

Unhook and take out the tool

bag.

Take out the jack.

For loosening

For tightening

CTH52AS020

STEP

1

CTH52AS004

STEP

2

CTH52AS035

STEP

3
