3-7. Other interior features

3

Interior features

4RUNNER_U

n Slide deck (if equipped)

Slide the deck while turning

the lock release lever, and

then release the lever after

sliding the deck to the lock

position.

Half-slide locked position

Full-slide locked position

n Grocery bag hooks

Type A

CTH37AS048

CTH37AS049
