3-6. Using the storage features

4RUNNER_U

NOTICE

n Items that should not be stowed in the bottle holders

Put the cap on before stowing a bottle. Do not place open bottles in the bot-

tle holders, or glasses and paper cups containing liquid. The contents may

spill and glasses may break.

Bottle holders
