61

1

Before driving

4RUNNER_U

1-3. Adjustable components (seats, mirrors, steering wheel)

Front seats

Manual seat

Seat position adjustment

lever

Vertical height adjustment

lever (driver’s side only)

Seatback angle adjustment

lever

Lumber support adjustment

switch (driver’s side only)

CTH13AS055
