250

2-4. Using other driving systems

4RUNNER_U

CANNOT BE

SELECTED

(When pressing the

“ON/OFF” switch)

Indicates that Multi-

terrain Select cannot

be operated because

vehicle speed

exceeds approxi-

mately 7 mph

(12 km/h).

Reduce vehicle speed.

OP. NOT POSSIBLE

WHEN CRAWL CON-

TROL ACTIVATED

(When pressing the

“ON/OFF” switch)

Indicates that Multi-

terrain Select cannot

be operated because

Crawl Control is oper-

ating.

Turn Crawl Control off.

Multi-terrain Select

HAS BEEN CAN-

CELED

(When pressing the

“ON/OFF” switch)

Indicates that Multi-

terrain Select is

turned off.

Multi-terrain Select

NOT AVAILABLE

(When pressing the

“ON/OFF” switch)

Indicates that Multi-

terrain Select cannot

be operated because

the VSC and/or 4WD

system may be mal-

functioning.

Contact your Toyota

dealer.

Message Details Procedure
