305

3-1. Using the air conditioning system and defogger

3

Interior features

4RUNNER_U

Air flows to the upper body and

feet.

Air flows to the feet.

Air flows to the feet and the

windshield defogger operates.

The air intake is automatically

switched to outside air mode.

CTH31AS010

CTH31AS011

CTH31AS012
