545

4-3. Do-it-yourself maintenance

4

Maintenance and care

4RUNNER_U

Partly remove the fender liner.

Unplug the connector while

depressing the lock release.

Turn the bulb base counterclock-

wise.

CTH43AS093

STEP

3

CTH43AS094

STEP

4

CTH43AS095

STEP

5
