5

When trouble arises

593

5-2. Steps to take in an emergency

4RUNNER_U

Multi-mode type

Pry the cover up with a flat-

head screwdriver or equiva-

lent tool.

Press the shift lock override

button.

The shift lever can be shifted

while the button is pressed.

CTH52AS021

STEP

4

CTH52AS022

STEP

5
