615

6-1. Specifications

6

Vehicle specifications

4RUNNER_U

How to read oil container label:

The ILSAC (International Lubricant Standardization and Approval

Committee) Certification Mark is added to some oil containers to help

you select the oil you should use.

CTH61AS018
