Link Layer Discovery Protocol
3-185
3
critical to the timely startup of LLDP, and therefore integral to the rapid availability
of Emergency Call Service.
Web – Click LLDP, Configuration. Enable LLDP, modify any of the timing parameters
as required, and click Apply.
Figure 3-111 LLDP Configuration
CLI – This example sets several attributes which control basic LLDP message
timing.
Configuring LLDP Interface Attributes
Use the LLDP Port/Trunk Configuration to specify the message attributes for
individual interfaces, including whether messages are transmitted, received, or both
transmitted and received, whether SNMP notifications are sent, and the type of
information advertised.
Console(config)#lldp 4-195
Console(config)#lldp refresh-interval 60 4-197
Console(config)#lldp holdtime-multiplier 10 4-195
Console(config)#lldp tx-delay 10 4-198
Console(config)#lldp reinit-delay 10 4-198
Console(config)#lldp notification-interval 30 4-196
Console(config)#lldp medFastStartCount 6 4-196
Console(config)#exit
Console#show lldp config
LLDP Global Configuation
LLDP Enable : Yes
LLDP Transmit interval : 60
LLDP Hold Time Multiplier : 10
LLDP Delay Interval : 10
LLDP Reinit Delay : 10
LLDP Notification Interval : 30
.
.
.
