Configuring the Switch
3-212
3
CLI – This example configures VoIP traffic settings for port 2 and displays the
current Voice VLAN status.
Configuring Telephony OUI
VoIP devices attached to the switch can be identified by the manufacturer’s
Organizational Unique Identifier (OUI) in the source MAC address of received
packets. OUI numbers are assigned to manufacturers and form the first three octets
of device MAC addresses. The MAC OUI numbers for VoIP equipment can be
configured on the switch so that traffic from these devices is recognized as VoIP.
Command Attributes
Console(config)#interface ethernet 1/2
Console(config-if)#switchport voice vlan auto 4-283
Console(config-if)#switchport voice vlan security 4-284
Console(config-if)#switchport voice vlan rule oui 4-284
Console(config-if)#switchport voice vlan priority 5 4-285
Console(config-if)#exit
Console#show voice vlan status 4-286
Global Voice VLAN Status
Voice VLAN Status : Enabled
Voice VLAN ID : 1234
Voice VLAN aging time : 1440 minutes
Voice VLAN Port Summary
Port Mode Security Rule Priority
-------- -------- -------- --------- --------
Eth 1/ 1 Auto Enabled OUI 6
Eth 1/ 2 Auto Enabled OUI 5
Eth 1/ 3 Manual Enabled OUI 5
Eth 1/ 4 Auto Enabled OUI 6
Eth 1/ 5 Disabled Disabled OUI 6
Eth 1/ 6 Disabled Disabled OUI 6
Eth 1/ 7 Disabled Disabled OUI 6
Eth 1/ 8 Disabled Disabled OUI 6
Eth 1/ 9 Disabled Disabled OUI 6
Eth 1/10 Disabled Disabled OUI 6
Eth 1/11 Disabled Disabled OUI 6
Eth 1/12 Disabled Disabled OUI 6
Eth 1/13 Disabled Disabled OUI 6
Eth 1/14 Disabled Disabled OUI 6
Eth 1/15 Disabled Disabled OUI 6
Eth 1/16 Disabled Disabled OUI 6
Eth 1/17 Disabled Disabled OUI 6
Eth 1/18 Disabled Disabled OUI 6
Eth 1/19 Disabled Disabled OUI 6
Eth 1/20 Disabled Disabled OUI 6
Eth 1/21 Disabled Disabled OUI 6
Eth 1/22 Disabled Disabled OUI 6
Eth 1/23 Disabled Disabled OUI 6
Eth 1/24 Disabled Disabled OUI 6
Eth 1/25 Disabled Disabled OUI 6
Eth 1/26 Disabled Disabled OUI 6
Eth 1/27 Disabled Disabled OUI 6
Eth 1/28 Disabled Disabled OUI 6
Console#
