B
VEHICLE SPECIFICATIONS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
131
Repair and Service Manual
10002660
VEHICLE SPECIFICATIONS
Tracker EViS
Item Specification
Overall Length 112 in (2824 cm)
Overall Width 52 in (132 cm)
Overall Height 76 in (193 cm)
Wheelbase 70 in (178 cm)
Ground Clearance at Frame 16.5 in (41 cm)
Ground Clearance at Differential 9.5 in (24 cm)
Power Source 72 Volts DC
Motor Type 72 Volt AC
Horsepower (kW) 38 hp (28.3 kW) Peak
Electrical System 72 Volt
Battery Quantity and Type Six 12V Deep Cycle
Key or Pedal Start Pedal Start
Battery Charger 72 VDC DPI, 120 VAC 60 Hz
Speed Controller 300 Amp AC Controller
Drive Train Motor Shaft Direct Drive
Trans-axle Differential w/ Hardened Helical Gears
Gear Selection Dash mounted Forward-Neutral-Reverse
Speed Selection Dash Mounted Speed/Range Switch
Rear Axle Ratio 12.49:1
Front Axle Ratio 12.49:1
Seating Capacity 4 People
Curb Weight 1780 lb. (808 kg)
Vehicle Load Capacity 940 lb (426 kg)
Gross Front Axle Rating 749 lb (340 kg)
Gross Rear Axle Rating 1912 lb (868 kg)
Outside Clearance Circle 24.5 ft. (7.5 m)
Speed - Low (Level Ground) 16 mph (25.7 kph)
Speed - High (Level Ground) 24.5 mph (39.4 kph)
Speed - Reverse (Level Ground) 10 mph (16.1 kph)
Towing Capacity 1000 lb 454(kg)
Steering Self-compensating rack and pinion
Front Suspension Coil springs with MacPherson Struts
Rear Suspension Coil springs with MacPherson Struts
Service Brake 4-wheel Hydraulic Disc Brakes and Induction Motor
Parking Brake Speed Based Electronic Motor Brake
Front Tires Carlisle Trail Pro 25 x 8 - 12
Rear Tires Carlisle Trail Pro 25 x 10 - 12
Frame Welded steel with E-Shield ecoat plus DuraShield™ powder coat
Body and Finish Injection molded TPO
