B
64
Repair and Service Manual
FRONT CV SHAFT, SUSPENSION, AND STEERING
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
10002660
Steering Column Replacement
Tool List Qty.
Socket, 15mm.............................................................. 1
Socket, 24mm.............................................................. 1
Ratchet ........................................................................1
Wrench, 15mm ............................................................1
Torque Wrench, ft. lbs.................................................. 1
1. Remove the steering wheel. (See Steering Wheel
Replacement on page 63)
2. Remove the four bolts (41) and lock nuts (42) that
secure the steering column (40) to the frame.
3. Remove the yoke bolts (44), lock washers, and nuts
(46) to release the steering yoke (43) from the steer-
ing column (40) and steering rack (45) (Ref. Fig. 11).
Assemble in the reverse order of removal.
Tighten hardware to torques values specified below.
Fig. 11 Steering Column
Item Torque Specification
42 25 - 35 ft. lbs. (34 - 47 Nm)
38 20- 25 ft. lbs. (27 - 34 Nm)
44 25 - 30 ft. lbs. (34 - 41 Nm)
