Tracker Off-Road EViS 2020 - Batteries Removal

B
14
Repair and Service Manual
BATTERIES AND BATTERY CHARGER
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
10002660
Fig. 1 Battery System
Batteries Removal
Tool List Qty.
Insulated Wrench, 1/2” ................................................ 1
Insulated Wrench, 9/16” .............................................. 1
Insulated Socket, 1/2”, ................................................1
Insulated Socket, 9/16”................................................ 1
Ratchet ........................................................................1
Battery Carrier .............................................................1
Torque Wrench, ft. lbs.................................................. 1
Torque Wrench, in. lbs. ................................................1
Putty Knife ...................................................................1
Wire Brush ...................................................................1
Terminal Spreader .......................................................1
NOTICE: Hardware that is removed must always be
installed in its original position unless otherwise
specified. If torque values are not specified, refer to
the Torque Specifications table (See TORQUE
SPECIFICATIONS on page 5).
6
1
4
8
2
3
11
7
10
7
2
8
5
4
Front of Vehicle
