B
BATTERIES AND BATTERY CHARGER
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
21
Repair and Service Manual
10002660
Fig. 11 Charger Installation
The charger can remain connected to the AC outlet. To
charge the vehicle, refer to the instruction labels on the
charger. Insert the polarized DC plug completely into the
vehicle receptacle. The charger will automatically start a
few seconds after the plug is connected. The charger will
automatically stop when the batteries are fully charged,
and the DC plug can be removed from the vehicle.
NOTICE: Routing the DC cord through the steering
wheel when charging the batteries, serves as a
good reminder to store the cord out of the way when
charging is complete. The DC plug can be damaged
by driving over or catching the cord on the vehicle
when driving away.
An ungrounded electrical device
can become a physical hazard that
could result in an electrical shock
or electrocution.
Provide Protection From Elements
Do Not Block
Louvered Airways
NEMA 15 - 5R Grounded AC Receptacle
110 - 120 VAC. Dedicated 20 AMP Circuit
Locations outside the US and Canada:
Reference appropriate local electrical
code and charger manufacturer
recommendations for AC power
requirements.
