B
SEATING AND OPS
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
83
Repair and Service Manual
10002660
Fig. 14 Lower OPS Weldment
Assemble in the reverse order of removal.
Tighten hardware to torques values specified below.
110
121
122
123
124
126
125
128
129
127
128
Front of Vehicle
115
Item Torque Specification
124, 126 6 - 7 ft. lbs. (8 - 10 Nm)
111 15 - 19 ft. lbs. (20 - 25 Nm)
125 19 - 22 ft. lbs. (25 - 30 Nm)
127 30 - 33 ft. lbs. (40 - 45 Nm)
To Next Page
