TracVision TV3 User’s Guide
97
Specifications
System Specifications
NOTE: All specifications are subject to change without notice.
TracVision TV3 Antenna Specifications
Attribute Rating
Meets Inmarsat BGAN operational, survival, vibration, and shock
specifications
Dimensions 15.5" (39.4 cm) OD x 17.6" (44.7 cm) H
Weight
• Linear dual-output version: 20 lbs (9.1 kg)
• All other versions: 17 lbs (7.7 kg)
Temperature Operating: -13°F to +131°F (-25°C to 55°C)
Survival: -13°F to +158°F (-25°C to +70°C)
Input power 42 VDC (from TV-Hub), 42 W nominal
Minimum EIRP 50 dBW (Ku-band)
Frequency range 10.7 to 12.75 GHz
Polarizations
• Vertical/horizontal, high/low band
• Simultaneous LHCP (left-hand circular
polarization) and RHCP (right-hand
circular polarization)
LNB options
• Linear Universal Single
• Linear Universal Dual
•Circular
Elevation range 10° to 80°
Azimuth range
• Linear Universal Dual version: 720°
• All other versions: Continuous
Skew control Manual
Cable connections 75 type “F” connector
