CVHE-SVX005C-EN
11
Type of Requirement
Trane Supplied
Trane Installed
Trane Supplied
Field Installed
Field Supplied
Field Installed
Foundation
• Meet foundation requirements
Rigging
• Safety chains
• Rigging shackles
• Lifting beam
Disassembly/Reassembly
(as required)
• Trane will perform or have
direct on-site supervision of
the disassembly and
reassembly work (contact
your local Trane office for
pricing)
Isolation
• Isolation pads or spring
isolators
• Isolation pads or spring isolators
• Optional spring isolators, when required, are installed by
others; do NOT overload springs and do NOT install
isolation springs if they block serviceable parts such as the
oil tank system, service valves, etc.
Electrical
• Circuit breakers or fusible
disconnects (optional)
• Unit-mounted starter
(optional)
• Power factor correction
capacitors (PFCCs)
(optional)
• Jumper bars
• Temperature sensor
(optional outdoor air)
• Flow switches (may be
field supplied); for
installation instructions for
the ifm efector® flow
detection controller and
sensor, refer to “Water
Flow Detection Controller
and Sensor ,” p. 31 or
Trane literature that
shipped with the device
• Remote-mounted starter
(optional)
• Air-Fi® wireless
communication (optional)
• Wi-Fi wireless
communication (optional)
• Circuit breakers or fusible disconnects (optional)
• Electrical connections to unit-mounted starter (optional)
• Electrical connections to remote-mounted starter (optional)
• Wiring sizes per submittal and National Electric Code
(NEC)
• PFCCs (remote mounted starter optional only)
• Terminal lugs
• Ground connection(s)
• Jumper bars
• BAS wiring (optional)
• Inter-processor communication (IPC) wiring (AFD and
remote-mounted starters only)
• Control voltage wiring (AFD and remote-mounted starters
only)
• Oil pump interlock wiring (AFD and remote mounted
starters only)
• High condenser pressure interlock wiring (AFD and
remote-mounted starters only)
• Chilled water pump contactor and wiring including interlock
• Condenser water pump contactor and wiring including
interlock
• Option relays and wiring
• Symbio 800 BAS communication wiring (optional)
Water piping
• Flow sensing devices
(may be field supplied)
• Taps for flow sensing devices
• Taps for thermometers and gauges
• Thermometers
• Strainers (as required)
• Water flow pressure gauges
• Isolation and balancing valves in water piping
• Vents and drain on waterbox valves (one each per pass)
• Pressure relief valves (for waterboxes as required)
Relief
• Rupture disk assembly
• RuptureGuard™ (optional);
refer to Installation,
Operation, and
Maintenance:
RuptureGuard Pressure
Relief System Option
(CTV-SVX06*-EN)
• Vent line and flexible connector and vent line from rupture
disk to atmosphere
Insulation
• Insulation (optional)
• Insulation
• Chiller feet insulation
Pre-Installation
