20
CVHE-SVX005C-EN
Table 3. Representative weights, 50 Hz chillers (lb) (continued)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHG
480–565 489 050S 050S 22258 19747 22815 20304
480–565 489 050S 050L 23274 20504 23831 21061
480–565 489 050L 050L 24391 21244 24948 21801
480–565 489 050S 080S 25874 22538 26431 23095
480–565 489 050L 080L 28712 24647 29269 25204
480–565 489 080S 080L 33279 28754 33836 29311
670–780 621 080S 080S 32952 28732 33509 29289
670–780 621 080S 080L 34540 30015 35097 30572
670–780 621 080L 080L 36561 31431 37118 31988
670–780 621 080L 142L 45020 38203 45577 38760
670–780 621 142M 142L 49518 41562 50075 42119
670–780 621 142L 142L 50789 42475 51346 43032
920–1100 621 080L 142L 46086 39269 46643 39826
920–1100 892 142M 142L 50988 43032 51545 43589
920–1100 892 142L 142L 52259 43945 52816 44502
920–1100 892 142M 210L 56984 47879 57541 48436
920–1100 892 142L 210L 58205 48792 58762 49349
920–1100 892 142E 210L 59630 49778 60187 50335
920–1100 892 210L 210L 63821 53751 64378 54308
Notes:
1. TECU tubes, 0.028 in. tube wall thickness.
2. 300 psig marine waterboxes.
3. Heaviest possible bundle and motor combination.
4. Operating weights assume the largest possible refrigerant charge.
5. Weights with starters assume the heaviest possible starter (AFD when it’s an allowed option).
6. Industrial Control Panel (INDP) option, add 50 lb.
7. Control Power Transformer (CPTR) option, add 130 lb.
8. Supplemental Motor Protection (SMP) option, add 500 lb.
Weights (kg)
Important: The weight information provided here should be
used for general information only. Trane does
not recommend using this weight information
for considerations relative to chiller handling,
rigging, or placement. The large number of
variances between chiller selections drives
variances in chiller weights that are not
recognized in these tables. For specific
weights for your chiller, refer to your submittal
package.
Unit Clearances and Weights
