Trane CenTraVac CVHE - Page 19

CVHE-SVX005C-EN
19
Table 3. Representative weights, 50 Hz chillers (lb)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHE
190–320
215
032S 032S
14785 13426 — —
231 — — 16456 15097
190–320
215
032S 032L
15390 13881 — —
231 — — 17061 15552
190–320
215
032L 032L
16234 14531 — —
231 — — 17905 16202
190–320
215
050S 050S
19696 17195 — —
231 — — 21419 18918
190–320
215
050S 050L
20712 17952 — —
231 — — 22435 19675
190–320
215
050L 050L
21829 18682 — —
231 — — 23636 20502
300–500
360
050S 050S
21307 18806 — —
379 — — 22608 20107
300–500
360
050S 050L
22323 19563 — —
379 — — 23624 20864
300–500
360
050L 050L
23524 20390 — —
379 — — 24825 21691
300–500
360
050S 080S
24923 21589 — —
379 — — 26224 22890
300–500
360
080S 080S
30740 26520 — —
379 — — 32041 27821
300–500
360
080S 080L
32328 27803 — —
379 — — 33629 29104
300–500
360
080L 080L
34349 29219 — —
379 — — 35650 30520
Unit Clearances and Weights
