16
CVHE-SVX005C-EN
Table 1. Clearance requirements (continued)
Evaporator Size
Shell Combo
A B C D E
in. cm in. cm in. cm in. cm in. cm
080 Short/Long
Short/Short 53 134 141 358 329 835 36 91 76 193
Short/Long
85 215 219 556 439 1115 36 91 76 193
Long/Long
53 134 187 474 419 1064 36 91 76 193
142 Medium/Long/
Extended
210 Long
Medium/Long
78 198 207 525 444 1127 44 111 92 233
Long/Long
58 147 187 474 424 1076 44 111 92 233
Extended/Long
58 147 209 530 469 1191 44 111 92 233
Long/Long
59 149 187 474 426 1082 47 119 102 259
250 Extended
Extended/Long
63 160 209 530 475 1206 43 109 115 292
Note: All dimensions are approximate; refer to the unit submittal package for exact dimensions for your unit.
General Weights
Weights (lb)
Important: The weight information provided here should be
used for general information only. Trane does
not recommend using this weight information
for considerations relative to chiller handling,
rigging, or placement. The large number of
variances between chiller selections drives
variances in chiller weights that are not
recognized in these tables. For specific
weights for your chiller, refer to your submittal
package.
Unit Clearances and Weights
