Trane CenTraVac CVHE - Unit Components

14
CVHE-SVX005C-EN
Unit Components
Note: The control panel side of the unit is always
designated as the front side of the unit.
Figure 3. Typical CVHF CenTraVac™ chiller
1
2
3
4
5
6
7
8
9
0
-
0
1. Suction Elbow
2. Compressor
3. Terminal Box
4. Control Panel
5. Condenser
6. Motor Housing
7. Economizer
8. Oil Tank Assembly
9. Purge
10. Evaporator
11. Display Panel
