To understand how the data is interpreted, it is necessary to break down the GSE Mask
field, A4, into binary:
A4 = 1010 0100
This mask equates to the tag comparing the first, third, and sixth bytes of the
Comparison Data to data in the tag beginning at address location 0A (10 decimal).
The Comparison Data field is broken down in bytes with the bytes corresponding to the
mask underlined in bold (for clarification):
Address: 0A 0B 0C 0D 0E 0F 10 11
Data: 00 05 01 42 02 02 41 33
where
0A (10 decimal) must be equal to “00” hexadecimal, the first byte in the Comparison Data
field
0C (12 decimal) must be equal to “01” hexadecimal, the third byte in the Comparison Data
field
0F (15 decimal) must be equal to “02” hexadecimal, the sixth byte in the Comparison Data
field
Reader response: #Done
Auxiliary Reader Control — Command Group 8
Group 8 commands provide control of reader functions, such as the sense input lines.
8110 Switch on RF Port 0, Fire O Check Tag Address 0 on Check Tag Pin 0
#8110 turns on RF port 0 and sends the command on Ctag pin 0 to fire o Ctag address 0.
8111 Switch on RF Port 1, Fire O Check Tag Address 1 on Check Tag Pin 0
#8111 turns on RF port 1 and sends the command on Ctag pin 0 to fire o Ctag address 1.
8112 Switch on RF Port 2, Fire O Check Tag Address 0 on Check Tag Pin 1
#8112 turns on RF port 2 and sends the command on Ctag pin 1 to fire o Ctag address 0.
8113 Switch on RF Port 3, Fire O Check Tag Address 1 on Check Tag Pin 1
#8113 turns on RF port 3 and sends the command on Ctag pin 1 to fire o Ctag address 1.
8142X Set Check Tag Character on Check Tag Pin 0
#8142X sends the command on Ctag pin 0 to set the Ctag character.
8143X Set Check Tag Character on Check Tag Pin 1
#8143X sends the command on Ctag pin 1 to set the Ctag character.
8150 Set Check Tag Address to 0 on Check Tag Pin 0
#8150 sets the check tag address to 0 on check tag pin 0.
