Installation (for qualified installers only) 19
© Travis Industries 3/13/18 - 1474 42 & 54PB GSB2 Aust.
5 On the header shield, bend the two tabs downward approximately 90 degrees. Set the header shield
onto the standoffs with the 90° bend facing the pipe shield. The tips of the standoffs will protrude through
the heat shield. Attach the heat shield to the standoffs by aligning the holes on the heat shield tabs with
the holes in the header standoffs and secure using the included screws
6 When finished the fireplace should be configured like the picture below.
Bend tabs
To Next Page
