PoE Web Smart Switch Series
IPv4 ARP Aging Time
System > L3 Feature > IPv4 ARP Aging Time
This section allows you to set the timeout for the switch’s ARP Table per each
configured VLAN.
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on System, L3 Feature, and then IPv4 ARP Aging Time.
3. Click on Edit to change the value, then click Apply.
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, click Save Settings to Flash,
then click OK.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
IPv4 Static ARP
System > L3 Feature > IPv4 Static ARP
This section allows you to statically set ARP entries per each configured VLAN.
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on System, L3 Feature, and then IPv4 Static ARP.
3. To add a static ARP entry, fill out the following fields and then press Apply. To delete
an entry, press Delete in the lower table.
IP Address: enter the IP address you would like to statically set to the ARP table.
Hardware Address: enter the MAC address that you would like to assign to the IP
entered above.
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, click Save Settings to Flash,
then click OK.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
