TRENDnet PoE Web Smart Switch Series User Manual

© Copyright 2018 TRENDnet. All Rights Reserved.
75
TRENDnet User’s Guide
PoE Web Smart Switch Series
Protocol VLAN Profile Interface
Network > Protocol VLAN > Protocol VLAN Profile Interface
1. Log into your switch management page (see “Access your switch management page”
on page 5).
2. Click on Network, click on Protocol VLAN, and click on Protocol VLAN Profile
Interface.
3. Configure the new Protocol Interface. Click Apply to save.
 Port – Select the port number from the dropdown.
 Profile ID– Select the profile ID from the drop down.
 VID – Assign a VID.
 Priority – Select a priority level from the dropdown menu
4. At the bottom of the left hand panel, click Save.
5. Select the Config you would like to save the settings to, click Save Settings to Flash,
then click OK.
Note: This step saves all configuration changes to the NV-RAM to ensure that if the
switch is rebooted or power cycled, the configuration changes will still be applied.
