TRENDnet TEW-718BRM User Manual

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-718BRM
39
• DHCP Server – Enable or Disable the DHCP server.
• IP Pool Starting Address – Changes the starting address for the DHCP server
range. (e.g. 192.168.10.20)
• IP Pool Starting Address – Changes the last address for the DHCP server range.
(e.g. 192.168.10.30)
Note: The Start IP and End IP specify the range of IP addresses to automatically
assign to computers or devices on your network.
• Lease Time – Specifies the DHCP client lease time in seconds.
• Domain Name (Optional) – Specifies a domain name to assign to computers or
devices. (e.g. trendnet.com)
• DHCP Server Relay – If you have an external DHCP server and do not want to
use the router’s built-in DHCP server. To enable this setting, click Enable.
• DHCP Server IP – If DHCP Server Relay is enabled, enter the IP address of your
external DHCP server to relay DHCP requests.
Note: The DHCP lease time is the amount of time a computer or device can keep an
IP address assigned by the DHCP server. When the lease time expires, the computer
or device will renew the IP address lease with the DHCP server, otherwise, if there is
no attempt to renew the lease, the DHCP server will reallocate the IP address to be
assigned to another computer or device.
4. To save changes, click Apply.
Note: Clicking the More… option will allow you to configure additional parameters for
your DHCP server on your router to assign to computers or devices on your network.
Clients List – If you click Clients List, you can view the list of active lease entries for
computers or devices that have been assigned IP addresses automatically from the
DHCP server on your router.
The DHCP Clients List will allow you to select multiple clients and assign DHCP
reservation by selecting and clicking Fixed Mapping.
• Delete – Deletes the selected DHCP client device from the DHCP Clients List
table.
• Back – (At the bottom of the page) Returns you to the main DHCP server
configuration page.
• Refresh –(At the bottom of the page) Refreshes the DHCP Clients List.

TRENDnet TEW-718BRM Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Rack mounting	No
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DSL specification	G.992.1, G.992.2, G.992.3, G.992.5
DHCP client	-
Routing protocols	IGRP, IP, RIP-1, RIP-2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2-PSK
Antennas quantity	1
Certification	CE, FCC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	5 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Product color	Black
LED indicators	DSL, LAN, WLAN

Weight and Dimensions

Depth	189 mm
Width	118 mm
Height	33 mm
Weight	221 g
