42
Model Three - Operation Manual
Aud Offset - Press the
FCN
0
key to switch to Numeric Entry mode
and enter the positive offset of the audio frequency from the video
carrier. Press the
F
1
F
1
(ENTER) key to store the change (this
parameter appears for TV type only).
Measure BW - Press the
FCN
0
key to switch to Numeric Entry mode
and enter the measurement bandwidth for this channel. Press the
F
1
F
1
(ENTER) key to store the change (this parameter appears for
DIGI and SIGL types only).
Mode Type - Press the
F
1
F
1
(ENTER) key to select the modulation
type (this parameter appears for DIGI type only).
SR - Press the
FCN
0
key to switch to Numeric Entry mode and enter
the Symbol Rate (MS/s) for the channel. Press the
F
1
F
1
(ENTER) key
to store the change (this parameter appears for DIGI type only).
When you are satisfied with your entries, highlight SAVE AND EXIT
and press the
F
1
F
1
(ENTER) key to return to the Edit User Plan
screen.
Adding a Channel: A channel may be added while in the Edit User
Plan list of channels by pressing the
__
key. A Channel Edit screen
appears for the new channel with the next available channel number
assigned. This channel number may be changed, but an existing
number in the plan (enabled or not) may not be used. Other
parameters on the new Channel Edit screen should be set, including
frequency, which has a default setting of 55.25 MHz. When finished,
select SAVE AND EXIT and press the
F
1
F
1
(ENTER) key to return to
the Edit User Plan screen.
All channels, including a new channel, appear in the Channel Plan
according to frequency—not channel number.
The new frequency you enter should always
be less than 1000 MHz.
