61
Model Three - Operation Manual
To change the center frequency, press the
FCN
FCN
0
key to place the keypad in
its numeric function. Enter the desired new center frequency and press
the
F
1
F
1
(ENTER) key. If you enter an incorrect digit, do not press the
F
1
F
1
key. Instead, press the
F
2
(BACK) key. You can exit the
procedure by pressing the
F
3
(ESC) key to return to the original center
frequency.
The Spectrum mode can be set to hold the maximum (peak) spectrum
data for display. Each time the
SPECT
SPECT
6 PQR
key is pressed, the Model Three
switches between Live and Max modes. MAX appears in the upper-right
corner of the display when this mode is used. The Max hold data is
retained as long as the Model Three is on. To reset the Max hold data in
Spectrum mode, you must select RESET MAX HOLD in the
MEASUREMENTS SETUP menu.
You may wish to stop the scanning process so you can study the graph.
In the Spectrum screen, simply press the
F
1
F
1
(HOLD) key. The scan
marker stops moving. To resume scanning, press the
F
1
F
1
(TRIG) key.
Other functions are available by using the
F
3
key to change the function
of the
F
1
F
1
and
F
2
keys.
Press the
F
3
key to change the function of the
F
1
F
1
and
F
2
keys to
Scale and Ref. Change the display scale by pressing the
F
1
F
1
(SCALE)
soft key. Change the reference level by pressing soft key
F
2
(REF) and
using the
__
and keys to change the reference.
Press the
F
3
key to change the function of the
F
1
F
1
and
F
2
keys to
Auto and ΔMkr. To set the reference level and the scale automatically,
press the
F
1
F
1
(AUTO) key. The Model Three selects the optimal scope
for your system.
While in the Spectrum mode, you can use
Fast Setup (press SET once) to go directly to
the Measurement Setup parameters, including
Reset Max Hold.
