Trilithic Three - Page 92

90
Model Three - Operation Manual
Tilt Test - This data record is listed with the Tilt Level displayed at the
top of the screen. Use the
F
2
and
F
3
keys to scroll to any Tilt/
Favorite channel to see the Video level.
Spectrum Test - This data record lists the frequency and signal level
for each data point in the Spectrum test. Use the
F
2
and
F
3
keys
to scroll to any listed frequency in the Spectrum scan.
Scan Test - This data record lists all Video and Audio levels for each
channel in the Scan test. Use the
F
2
and
F
3
keys to scroll to any
channel.
Level Test - This data record lists all Video and Audio levels for each
channel in the Level test. Use the
F
2
and
F
3
keys to scroll to any
channel.
On any listed record, you can use the
__
and
keys to scroll through the channel list
(data points for Spectrum test) by one page
(eight channels) at a time.
The Pass or Fail indication for the Limit test is
based on the Limit test parameter setup at the
time the Limit test was performed. A digital
(DIGI) type Channel measurement during the
Limit test is shown but is not used to
determine Pass or Fail for any of the tests.
