Trimble R8 Operation
14.1 Introduction
Figure 14.1 shows the Trimble R8 receiver front panel controls for the
power on/off functions, or receiver reset. The LEDs provide power,
radio, data logging, and SV tracking status information.
Figure 14.1 Controls and LEDs on front panel of the Trimble R8 receiver
F
Power button
SV Tracking
Radio
Power/Data status
LEDs
