Trimble R7/R8 GPS Receiver User Guide 159
Default Settings 18
Trimble R8 Operation
18.2 Default Settings
Table 18.1 defines the default settings for the Trimble R8 receiver, as
defined in the default application file.
Table 18.1 Default settings
Function Factory default
SV Enable All SVs enabled
General Controls: Elevation mask 13°
PDOP mask 7
RTK positioning mode Low Latency
Motion Kinematic
Serial Port 1: Baud rate 115,200
Format 8-None-1
Flow control None
Serial Port 2: Baud rate 115,200
Format 8-None-1
Flow control None
Input Setup: Station Any
NMEA/ASCII (all messages) All Ports Off
Streamed output All Types Off
Offset = 00
RT17/Binary All Ports Off
Reference position: Latitude 0°
Longitude 0°
Altitude 0.00 m HAE
Antenna: Type Trimble R8/5800 Internal
Height (true vertical) 0.00 m
Group All
Measurement method Bottom of mount
