Trimble R7/R8 GPS Receiver User Guide 13
Setting up the Receiver 3
Trimble R7 Operation
32.1 Front panel
Figure 3.2 shows the front panel of the Trimble R7. This panel
contains the five indicator LEDs, the two buttons, and the catch for the
CompactFlash/USB door.
Figure 3.2 Front panel
The two buttons control data logging, data management, power, and
settings. For more information, see Button Functions, page 38.
The indicator LEDs show the status of logging, power, satellite
tracking, and radio reception. For more information, see LED
Behavior, page 39.
USB door catch
2
3
t
Buttons
Indicator LEDs
CompactFlash/
