Trimble R7 User Manual

16 Software Utilities
144 Trimble R7/R8 GPS Receiver User Guide
Trimble R8 Operation
160.1 Adding frequencies for the 450 MHz internal radio
If your Trimble R8 receiver has the optional internal 450 MHz radio
installed, you must use WinFlash to add receiving frequencies to the
default list. If you purchased the transmit option, the broadcast
frequencies must be programmed at the factory.
To add radio receiving frequencies:
1. Start WinFlash.
The Device Configuration screen appears.
2. From the Device type list select Trimble R8 Receiver.
3. From the PC serial port field select the serial (COM) port on
the computer that the receiver is connected to.
4. Click
Next.
The Operation Selection screen appears. The Operations list
shows all of the supported operations for the selected device. A
description of the selected operation is shown in the Description
field.

Trimble R7 Specifications

General

Brand	Trimble
Model	R7
Category	GPS
Language	English
